Radar A09
The radar A09 is an advanced safety solution for barrier gates. Operating within a 9 – 24V voltage range and at a 79GHz frequency, it offers 4 frequency adjustment options for versatile use. With a rapid 100ms reaction time, it can instantly detect vehicles or pedestrians that enter its sensing range. Measuring 107.5*73.2*18 mm, this compact radar can withstand extreme temperatures from -40℃ to 85℃ and has an IP66 water resistance rating.
When integrated with a barrier gate, during the boom’s downward movement, if a vehicle or pedestrian enters the radar’s detection area, the radar A09 will immediately send an opening signal to the barrier gate, effectively preventing potential collisions and ensuring enhanced safety. Equipped with RS485 and Bluetooth interfaces, it’s ideal for parking systems and roadway control applications.
Quote
Technical Data
- Product Name: RADAR A09
- Work Voltage: 9~24V
- Frequency Range: 79GHz
- Frequency Adjustment: 4
- Reaction time: 100ms
- Dimension: 107.5*73.2*18 mm
- Applications: Parking System , Roadway control, etc
- Working environment: -40℃-85℃
- Connection Interface: RS485/blue tooth
- Water Resistance Level: IP66
