6505 DC Brushless Barrier Gate

The 6506 is an auto – barrier with a 24VDC brushless motor. It offers adjustable speed (fastest 1.2S), soft start/stop, and reverse/auto – close functions. Compatible with parking systems, loop detectors, etc., the hat and boom are equipped with LED lights that can switch between red and green.

Operating at 24VDC±5%, it accepts 220V/110V power. Working in 10% – 90% humidity (- 35°C – 70°C),  boom length optional: 6m (6s), 4m (3s), 3m (1.5s). IP54 – rated with 120W power, it supports manual operation during outages, with backup battery optional.
